PIR20 : Occupancy Sensor
|
||||||
Description
Description :
Omicron’s Passive Infrared Occupancy Sensor is a low-cost commercial and residential surface mount occupancy sensor. Advanced filtering reduces false triggering due to air movement and lighting changes. The sensor switches a dry contact which is wired to a separate controller. There is a tamper switch terminal as well, when the enclosure is opened up the central controller will be able to signal an alert.
Main Features:
– Intelligent logic control, anti false alarm efficiently
– Auto temperature compensation
– Pulse count adjustment
– Anti-white light interference
– Anti RF interference (20V/m-1GHz)
– Fresnel lens
– Wall installation
– SMT design adopted
– Alarm output N.C./N.O. Optional
Additional information
| Operating voltage | : 12VDC / 24 VAC |
|---|---|
| Current consumption | : <18mA (24VAC) |
| Detecting distance | : 12m |
| Detecting angle | : 110° |
| Self-testing time | : about 60S |
| Alarm indicator | : red LED |
| Alarm output | : N.C.or N.O., DC28V, 100mA |
| Anti dismantle output | : N.C., DC28V, 100mA |
| Range of coverage | : 11 distance, 8 middle, 5 vicinities |
| Sensor | : dual element infrared sensor |
| Operating temperature | : -10 ~ +50°C |
| Environment humidity | : 95%RH (non condensing) |
| Anti RF interference | : 10MHz ~ 1GHz 20V/m |
| Installation mode | : wall mounted or hanged in corner |
| Installation height | : 1.7 ~ 2.5m (2.2m is Proposed) |
| Outline Size | : 59(L) * 39.5(W) * 107(H) mm |
