S3300

S3300 : Hydrostatic Level Transmitter

Model : S3300
Type : Hydrostatic Level Transmitter
Accuracy : 0.25% of FS; 0.5% of FS
Protection : IP65
Range : 0 – 1000m
Output : 4-20mA, 0-5V, 0.5-4.5V, 0 – 10V
Download pdf [wpdm_package id=’1699′]

Description

Description :

S3300 series standard level transmitter design with consummate encapsulation technology, the perfect assembly process insure the quality and performance of this series with high stability, high accuracy, leakage proof.

Applications :

It can be used for liquid measuring for petroleum, metallurgy, hydraulic, city water supply, sewage treatment, hydrometry and etc.

Additional information

Pressure range

: 0 ~ 1mH2O~1000mH2O
Overload

: 150% of FS
Output

: 4-20mA, 0-5V, 0.5-4.5V, 0 – 10V
Power supply

: 12-36VDC
Combine error

: 0.25%FS; 0.5% FSO
(Including Linearity, Repeatability & Hysteresis)
Long term stability

: ± 0.2%FS/year
Repeatability

: ±0.2%FSO
Response time

: <10ms
Pressure connection

: 1/4" BSP (M)
Temp. compensation

: 0°C~65°C
Operating temp.

: 0'C~85°C
Protection grade

: IP65
