EX-200DPG Differential Pressure Switch

Model : EX-200DPG
Media : Wet / Wet
Enclosure : SS304 / Diecast Aluminium
Wetted Parts : SS316L
Range : 0 – 700 bar
Accuracy : ±2% of F.S
Electrical Rating : 15A, 250V AC
Download

Description

Special Features
  • Field Adjustable.
  • Compact and Reliable.
  • Snap Action Micro-switch with Piston.

Additional information

Sensor

: AISI 316L SS Piston

Wetted Parts

: AISI 316LSS

Enclosure

: SS304, Weatherproof to IP 65

Ambient temperature

: – 40°C to + 80°C

Process temperature

: -40 to 120°C

Operating pressure

: 75% of the Scale Value

Process Media

: Air, Oil and Water

Scale Accuracy

: ±2% of F.S.R

Repeatability

: ±0.5% of F.S.R

Max Static Pressure

: 25 Bar, 200 Bar, 450 Bar or 700 Bar

Process Connection

: 1/4” BSP (F)

Mounting

: In Line Mounting / Panel / Back / Bottom Entry

Switch

: 1 SPDT or 2 SPDT, Magnetic Reed Switch

Contact Rating

: 15VA, 0.5A, 125VAC / 200VDC 100VA, 2.0A, 230VAC / 300VDC

Dial Size

: 2.5”, 4”, 6”

Standard Ranges

: 0… 0.5, 1.0, 1.5, 2.0, 2.5, 3.0, 4.0, 5.0, 6.0, 7,0, 10 bar Other ranges available on demand
