Model |
: PGCG |
|
Type |
: Capsule Gauge |
|
Dial Size |
: 2.5" - 10" |
|
Range |
: 0 to 6000mmwc |
|
Wetted Parts |
: SS316 |
|
Case |
: SS304 |
|
 |
Special Features : |
|
Stainless steel case & ring |
|
Most suitable for air & gaseous application measurement from 25 mbar to 600 mbar |
|
Bottom & back mounting |
|
Vacuum & compound ranges |
|
Standard followed in general en 837-3 |
|
|
Applications : |
| Food & Beverages, Pharmaceutical, Conventional & Nuclear Power Plants, Draft Measurement |
|
Specifications : |
| Standard Version: 63mm, 100mm, 125 mm, 150mm |
|
Accuracy |
: ± 1.6%ofF.S. |
|
Ambient temperature |
: - 25°C to + 65°C |
|
Process temperature |
: Max150°C |
|
Operating pressure |
: 75 % of the Scale Value |
|
|
|
Case |
: AISI 304 SS |
|
Ring |
: AISI 304 SS, Bayonet Type |
|
Socket |
: AISI 316LSS |
|
Movement |
: AISI 304 SS |
|
Joints |
: Tig Argon Arc Welding |
|
Capsule |
: AISI 316 SS (With Laser Welded) |
|
|
|
Over Pressure |
: 110% F.S.D. |
|
Protection |
: IP 55 |
|
Dial |
: Aluminium, black graduation on white background with zero
adjustment provision |
|
Pointer |
: Aluminium, black Coloured, Fixed |
|
Window |
: Sheet Glass |
|
Gasket |
: Neoprene |
|
|
