Instrument |
: Flow Switch EX |
|
MOC |
: SS316 / Diecast Aluminium |
|
Max Pressure |
: 10 bar |
|
Accuracy |
: ±5% |
|
Enclosure |
: Explosion proof |
|
Output |
: 1 SPDT |
|
 |
Special Features : |
|
Rugged Construction |
|
Sealed Bellow type |
|
Available in Explosion-proof Housing |
|
|
Applications : |
| Paddle Type Flow Switches are rugged inconstruction. Model FSPT is a bellow sealed flow switch. These are used in fluid lines carrying non hazardous liquids like water, kerosene, glycol, ethylene, etc. |
|
Specifications : |
| Standard Version: 25NB, 40NB, 50NB |
|
Max System Pressure |
: 10 bar for Phosphor Bronze bellows
20 bar for Stainless Steel bellows |
|
Process temperature |
: 0 to 120 oC |
|
Pressure Drop |
: <80 mbar at Qmax |
|
Enclosure |
: General Purpose, Powder Coated Steel |
|
|
|
|
