TTD3N : Ambient Temperature Transmitter

Model : TTD3N
Download

Description

Applications & Features :
These transmitters/controllers can be used for temperature monitoring & controlling
in duct air
High performance digital temperature sensor, ensure accurate measurement
fast response and good long term stability
Multiple outputs selection, digital technology applied, over voltage and reverse
polarity protection, high reliability and interference capability
Optional relay for alarm or ON/OFF control
Light and state of art housing, easy installation
Wide working temperature range
MMI can set parameters and calibrate output, so that the product becomes a
stand alone
High protection rate up to IP65

Additional information

Sensor

: Digital temperature sensor

Range

: see models

Output

: 4~20mA(3 wires) , 0~10VDC , RS485 / Modbus

Relay

: 1×SPDT , 1A/30VDC or 0.5A/125VAC

Accuracy

: <±0.5°C@ -10~85°C

Power

: 15~28VAC/15~36VDC

Work Temperature

: -40~85°C, 0~95%RH (Non condensing)

Storage Temperature

: -40~85°C

Housing

: ABS, SS probe, SS well

Protection

: IP65

Agency Approval

: CE

Optional Accuracy

: 0.25°C @ -20 ~105°C (Add “H” after part numbers)
