S323: IP65 Differential Pressure Transmitter
Model : S323
Range : -500 to 500 mmwc
Output : 0-10 V / 4-20 mA
Accuracy : ±0.25% of F.S
Media : Air / Gases
Display : None

Specifications :

Maximum Pressure : Ranges ≤ 5 PSI (35 kPa) = 15 PSI (100 kPa) Max
Storage : Ranges > 5 PSI (35 kPa) = 30 PSI (200 kPa) Max
Media compatibility : Air and compatible non combustible,
  non corrosive gasses
Accuracy : Ranges ≤ 4” w.c. (1 kPa) 1.0% Ranges ≥
  5” w.c. (1.25 kPa) 0.25%
Temperature Ranges
Compensated : 15° to 120°F (-10° to 50°C)
Operating : -10° to 155°F (-25° to 70°C)
Thermal Effect : +/- 0.028% FS/°F (+/- 0.050%/° C)
Stability : +/- 0.25% FS/year
Output Signal : 4-20 mA, 2 wire or 0-10V
Loop Resistance : 250 Ω @ 24 VDC
Power Supply : 12-30 VDC
Enclosure Rating : IP 65
Electrical Connections : screw terminals
Electrical Entry : PG7 cable gland
Process Connection : Barbed fittings for 3/16” flexible tubing
Agency Approvals : CE
