AVT1 : Duct Mounted Air Velocity Transmitter

Special Features :

Based on Thermal Measurement Principles
Sensitive Hot Film Sensor
Strong Pollution Tolerance
Low Airflow Angle Dependance
Wide Velocity Range with Temperature Compensation
Multiple Outputs Available
Field Jumper Selection for Velocity Ranges

Applications :

AVT1 Air Velocity Transmitters Are Used For Various Applications To Detect, Adjust And Control Air Velocity In Ventilation Measurement And Control Systems To Satisfy The Relevant Ventilation Requirements And Effectively Reduce The Energy Consumption.

Specifications :

Range : 0 - 5 / 10 / 15 / 20 m/s (On Site Adjustable)
Output : 4 - 20mA (2 Wire), 0 - 10 VDC (3 Wire) Jumper Set
Power Supply : 18 - 30 V AC / V DC
Accuracy : ±0.2 m/s + 3% of Measurement Value
Temperature Range : 0 C to 50 C (Corresponding to 4 - 20mA / 0 - 10V Output)
Sensitivity : 0.001 m/s
Temperature Accuracy : ±0.5 C
Housing Material : Fireproof ABS Enclosure, Stainless Steel Probe
Relay Output : 1 SPDT, 1 A @ 30 VDC, 0.5A @ 250VAC (Optional)
Protection : IP65, NEMA 4X
Response Time : 2 sec
